IGS-RX164GP+

Industrial Layer-3 20-port managed Gigabit Ethernet switch with 16x10/100/1000Base-T(X) ports and 4x1G/10GBase-X, SFP socket

Overview
IGS-RX164GP+ advanced Layer 3 managed redundant ring Ethernet switch with 16x10/100/1000Base-T(X) ports and 4x10GBase-X SFP ports. The IGS-RX164GP+ supports routing protocols such as static routing, RIP v1/v2, OSPF and PIM which are suitable for large scale network environment. The hardware Layer 3 switch is optimized to transmit data as fast as Layer-2 switches. With completely support of Ethernet Redundancy protocol, O-Ring (recovery time < 30ms) and MSTP (RSTP/STP compatible) can protect your mission-critical applications from network interruptions or temporary malfunctions with its fast recovery technology. And support wide operating temperature from -40ºC to 75ºC. IGS-RX164GP+ can also be managed centralized and convenient by Open-Vision, as well as the Web-based interface, Telnet and console (CLI) configuration.

igs-9822dgp

Features

  • 112Gbps Switch bandwidth and 7µs latency
  • Support IPV6 new internet protocol version
  • Support routing protocols – Static routing, RIP v1/v2, OSPF, PIM-SM, PIM-DM, VRRP
  • Support TSN freature - IEEE 802.1AS for timing & Synchronization, IEEE 802.1Qav and IEEE 802.1Qat
  • Support O-Ring (recovery time < 30ms) and MSTP(RSTP/STP compatible) for Ethernet Redundancy
  • O-Chain allow multiple redundant network rings. Standard IEC 62439-2 MRP on request
  • Application-based QoS management, IGMP snooping support, Device Binding security, DOS/DDOS auto prevention
  • SNMP v1/v2c/v3 support; RMON for traffic monitoring
  • ACL and 802.1x User Authentication for security
  • Event notification through Syslog, Email, SNMP trap
  • Open-Vision support centralized management; configurable by Web, Telnet, Console, CLI
  • IEEE 802.3az Energy-Efficient Ethernet
  • Dual DC inputs
  • Rigid IP-30 housing; DIN-Rail and wall mounting

IGS-RX164GP+ Specifications

Interfaces

  • 16x 10/100/1000Base-T(X) ports in RJ45
  • 4 x 1G/2,5G/10GBaseX SFP ports
  • 1x RS232 Console Port (DB9)
  • Relay output
Regulatory Approvals

Power

  • Dual DC inputs. 12-48VDC on 6-pin terminal block
  • Power Consumption (Typ.) 23 Watts
  • Overload Current Protection Present

Environmental

  • Operating Temperature -40 to 75°C (-40 to 167°F)
  • Operating Humidity 5% to 95% Non-condensing

Physical Characteristics

  • Dimensions (mm): 116,4 (W) x 170 (D) x 180 (H)
  • Enclosure: metallic - IP30
  • Warranty 5 years

Accessories

  • NDR-75 series, 75W Din Rail Power Supply
  • SFP1G series 1Gbps SFP optical transceiver
  • SFP100 series 100Mbps SFP optical transceiver
  • Open-Vision M500, Network Management Windows
  • DBU-01 Device Configuration Backup Unit
